Basic Spinnaker Pole information

SPINNAKER POLES

Forespar® offers a complete and diversified line of spinnaker poles. We manufacture eight complete end styles from which we create a multitude of combinations to fit the needs of all sailors - racers or cruiser.

CUSTOM POLES & KITS

Forespar® offers "customized" poles built to specific dimensions, and also "kit" poles in which both ends are left loose to allow the marine dealer or yachtsman to finish the pole himself. End fittings and tubing are available separately for those who wish to assemble poles to their own specifications.

DETERMINING POLE LENGTH

The length of your spinnaker pole is determined by the yachts "J" measurement. This is roughly the straight line distance from the front of the mast at deck level to the headstay. The "J" measurement is available from your sailplan, or contact Forespar® and we will be able to assist you in determining the proper length.

The "kit" lengths that are shown on the following pages are the maximum we recommend for each tubing diameter. However, oversized poles are available.

FOR POLES WITH OUR TS & UTS END FITTING, AND USING A FORESPAR T-125-S CAR, 5" IS SUBTRACTED WHEN GIVEN A 'J' DIMENSION TO ESTABLISH POLE LENGTH.

Custom Carbon Fiber Spinaker Poles

Use our convenient Fax PDF Order form click here:

OFFSHORE POLES

Part No. Custom	Model Number	Shipping Weight	Kit Length (w/ends)	Description
302028	TS-300-GP	22 lbs.	14'	Socket Inboard/GP Outboard.
304115	UTS-300-UTR	18 lbs.	1.250" dia. - 13.5' kit	ULTRA Socket Inboard ULTRA Trigger Outboard.
304116	UTS-300-UGPS	19 lbs.	14'	ULTRA Socket inboard ULTRA GPS Outboard.
302032	TS-350-GP	35 lbs.	15.5'	Socket Inboard/GP Outboard.
304117	UTS-350-UTR	33 lbs.	15'	ULTRA Socket Inboard ULTRA Trigger Outboard.
304118	UTS-350-UGPS	34 lbs.	15'	ULTRA Socket inboard ULTRA GPS Outboard.
302036	TS-400-GP	47 lbs.	19'	Socket Inboard/GP Outboard.
304119	UTS-400-UGPS	44 lbs.	18.5'	ULTRA Socket Inboard ULTRA GPS Outboard.
302040	TS-450-GP	52 lbs.	21'	Socket Inboard/GP Outboard.
304120	UTS-450-UGPS	49 lbs.	20.5'	ULTRA Socket Inboard ULTRA GPS Outboard.

RETRACTABLE BRIDLE OPTION

For custom spinnaker poles 3" in diameter or large only. Featuring internal outboard-end trip lines, and a retractable topping lift, this rigging allows the sailor to smoothly complete a spinnaker jibe without detaching the pole from the mast.

Part No.

Description

Retail

300032

Retractable Bridle Option

$230.00

ABOUT THE CARE OF FITTINGS

Yachtsmen take particular care when painting or varnishing their hulls, looking after sails, spars and rigging, and then, for the most part, forget to maintain their poles, valves and deck fittings. The most effective method of keeping deck hardware (e.g. pole ends, cams etc.) working freely is to wash them thoroughly with fresh water after every race or cruise. This is especially important when using spinnaker/whisker poles, tiller extensions or other telescoping equipment. Salt and sand that is not cleaned out can destroy the locks, cams, springs or rollers in a matter of months. Forespar® strongly advises against the use of lubricants on pole ends and telescoping poles. This can clog spring housing and ball bearings and can destroy twist-lock components. As a general rule, all fittings on deck, whether a dinghy or an ocean racer, should be maintained regularly. As previously mentioned, the best treatment is fresh water washing/flushing. This attention to maintenance will ensure that every fitting on your yacht will function at its best and attain a maximum performance life.
